Technology Articles

2023-01 Sensors TDK

[Jan 16 2023] TDK's compact EPCOS E13EMHV series SMT transformers with high dielectric strength. This series of components is widely applicable to various DC-DC converter topologies. The electrical isolation distance complies with IEC 60664-1 and 61558-2-16 standards. The maximum operating voltage is 1000 V DC, and transient overvoltage can be tolerated up to 2500 Vpeak. And the withstand voltage between the p ...

2023-01 Sensors Omron Electronics Inc-EMC Div

[Jan 16 2023] Omron's E3AS photoelectric sensor improves part detection, especially when part characteristics change using time of flight (TOF) technology. Traditional triangulation methods are challenged by changing component colors, exotic profiles and varying reflectance. TOF technology detects objects based solely on the distance between them and the sensor, so it is not affected by changes in color or ref ...

2023-01 Power Maxim Integrated

[Jan 16 2023] Maxim Integrated's MAX86150 provides pleurogram (PPG) and electrocardiogram (ECG) measurements via a mobile battery-powered device for health monitoring. The MAX86150 is a biosensor module consisting of an internal light-emitting diode, photodetector, and ECG analog front end (AFE) that delivers highly accurate, FDA-approved PPG and ECG performance in compact power-saving designs that include mob ...

2023-01 Sensors Renesas Electronics America

[Jan 15 2023] Intersil's ISL8215M power module is a single channel synchronous step-down complete power supply capable of delivering up to 15 a continuous current. Operating from a single 7 V to 42 V wide input power track, the ISL8215M incorporates controllers, power inductors and MOSFEts optimized for space-constrained and battery-powered applications. With high efficiency, including optional light load mode ...

2023-01 Semiconductors TDK InvenSense

[Jan 15 2023] TDK InvenSense's SmartBug (MD-42688-P) is a multi-sensor wireless module that utilizes TDK MEMS sensors and algorithms for a wide range of iot applications. This module combines six sensors, a powerful wireless (BLE) MCU, seven algorithm-driven features, and a rechargeable battery all in a small ladybug case. It also offers an add-on board option that includes a Wi-Fi module, an SD card slot, and ...

2023-01 Semiconductors Texas Instruments

[Jan 15 2023] The Texas Instruments DAC60502 12-bit DAC is a high-precision, low-power device with a voltage output. The DAC60502 provides linearity of less than 1 LSB. The high accuracy of the tiny package makes the device ideal for applications such as gain and bias calibration, current or voltage set point generation and power supply control. The DAC includes a 2.5V, 5 ppm/°C internal reference that provide ...

2023-01 Semiconductors Texas Instruments

[Jan 15 2023] Texas Instruments' LM76002 and LM76003 regulators are easy to use synchronous step-down DC-DC converters capable of driving up to 2.5 A (LM76002) or 3.5 A (LM76003) load current from inputs up to 60 V. The LM76002 and LM76003 provide superior efficiency and output accuracy at very small solution sizes. Adopt peak current mode control. Other features such as adjustable switching frequency, synchro ...

2023-01 Sensors Sensirion AG

[Jan 14 2023] The Sensirion SFM4200 sensor is a digital flowmeter designed for high-flow applications. It can accurately measure the flow rate of air, oxygen and other non-corrosive gases. The SFM4200 is intended for traffic up to 160 slm. It operates at pressures of up to 8 bar and can withstand bursts of up to 13 bar. The SFM4200 uses a 5 V working supply voltage and has a digital two-wire I²C interface. The ...

2023-01 Semiconductors Vishay

[Jan 14 2023] Vishay Intertechnology, announced the launch of four new electronic fuses in a small 3 mm x 3 mm TDFN package with adjustable current Limit and overvoltage Protection (OVP) features -SiP32433A/B and SiP32434A/B. 3.5 A SiP32433A/B and 6 A SiP32434A/B operate in the input voltage range of 2.8V to 23 V -- up to 28 VIN DC -- integrating multiple control and protection functions, simplifying the desig ...

2023-01 Sensors ams

[Jan 14 2023] Ams OSRAM AS7343L 13-channel multi-spectral sensor. This compact sensor combines multi-channel color analysis with XYZ sensor technology to match the human eye's perception of color and light intensity. The AS7343L can be integrated into colorimeters, portable spectrometers, and consumer devices, allowing users to achieve greater productivity, flexibility, and richer functionality in color matchi ...

2023-01 Power Hirose Electric Co Ltd

[Jan 14 2023] Hirose's FH69 Series flip-back Printed Circuit Board (FPC)/ Flat Flexible Connector (FFC) connectors feature separate dual point contacts on top and bottom. The FH69 series delivers unmatched performance in harsh environmental conditions. The two-point contact system of the FH69 series uses a spring design to maintain a constant connection and is resistant to dust intrusion, shock and vibration. ...

2023-01 Power Diodes Incorporated

[Jan 13 2023] Diodes new multi - function - channel high - side power switches AP22980 can choose three different voltage conversion rates, so it can handle a wider capacitive load, while maintaining low surge current to ensure system stability. The power switch is ideal for portable electronics, computer hardware and solid-state data storage systems deployed in edge data centers. The AP22980 features an n-cha ...
