Technology Articles

2023-04 Power Texas Instruments

[Apr 10 2023] Texas Instruments TPS7A53A-Q1 Ultra-low drop voltage (LDO) regulator is a low-noise (5.6µV(RMS), high-precision, ultra-low drop voltage linear regulator (LDO) capable of providing 3A sources with a drop voltage of only 130mV. The combination of low noise, high PSRR, and high output current capabilities makes the TPS7A53A-Q1 designed to power noise-sensitive components such as radar power and info ...

2023-04 Power Allegro MicroSystems, LLC

[Apr 10 2023] Allegro MicroSystems 3D magnetic potential sensor integrated circuits are robust, high-performance, precise 3D magnetic sensing solutions that combine the extensive expertise of planar and vertical Hall technologies. 3D magnetic potential sensor integrated circuits provide a wide range of contactless motion detection that works with virtually any moving magnet system, simplifying magnetic design ...

2023-04 Sensors TDK

[Apr 7 2023] TDK's B84143CxS250/S251 series are EPCOS 3-wire EMC filters for high current converter applications. Depending on the type, they are rated for 305 VAC/530 VAC and 440 VAC/760 VAC (50 Hz/60 Hz) and for 160 A to 2500 A currents. A particular performance characteristic is the very high attenuation figures they achieve in the range of 9 kHz to 150 kHz. To meet UL requirements in open-cabinet construc ...

2023-04 Connectors Bourns

[Apr 7 2023] Bourns' magnetic product line offers AAC-Q200 compliant SRP1050WA, SRP5030WA, SRP6030WA and SRP7050WA series of high current shielding power inductors designed to meet the requirements of high current density and high temperature in harsh vibration operating environments for a variety of electronic applications. They are manufactured with metal alloy powder cores with low DC resistance, high satu ...

2023-04 Power Renesas Electronics America

[Apr 7 2023] The RAA2S4252B is a member of the Renesas CMOS integrated circuit family for high-precision amplification and sensor-specific correction of differential bridge sensor signals. The RAA2S4252B features 900 maximum analog preamplification and analog Sensor offset correction (XSOC), which can be adjusted for almost all resistance Bridges. Conditioning calculations are performed with a 16-bit RISC mic ...

2023-04 Power ECS

[Apr 7 2023] ECS 'ECX-1637B2 series of Surface Mount (SMD) crystals are packaged in industry standard 2.0mm x 1.6mm x 0.45mm 4-pad ceramic. These electronic components offer a wide frequency range from 16 MHz to 50 MHz. They offer tight stability options of ±10ppm, tolerance of ±10ppm, and first year aging at low ±2ppm at +25°C±3°C, with the option of an extended operating temperature range. The standard ECX- ...

2023-04 Sensors Amphenol LTW

[Apr 7 2023] Amphenol LTW's overpressure release vent comes in a metal and plastic casing that balances the pressure inside and outside the sealed casing to prevent shortening the service life of the device and prevent potential damage to the internal components, performance degradation, or sudden heat/pressure rise of the battery module resulting in an explosion. IP68/IP69K waterproof protection and hydropho ...

2023-04 Sensors TDK-Lambda

[Apr 7 2023] TDK Lambda's CCG1R5 (1.5W) and CCG3 (3W) components can be operated at full load in the temperature range of -40°C to +85°C under convection-cooled conditions. These models consist of 36 voltage and current combinations and have 3.3V, 5 V, 12 V, 15 V and dual ±12 V and ±15 V outputs. Dual output models can also be connected to 24 V and 30 V power supplies. They can all operate at 4.5 V to 18 V, 9 ...

2023-04 Power KEMET

[Apr 3 2023] KEMET's full range of axial and radial coronal capacitors for automotive applications includes the Ultra High CV PEG227 and PEH227 series. KEMET's capacitors have excellent electrical performance and high energy storage capacity. They are rated for temperatures ranging from -40°C to +125°C or -40°C to +150°C at derated voltages. The series uses a polarized all-welded design with tinned copper lea ...

2023-04 Sensors ABB Embedded Power

[Apr 3 2023] ABB Embedded Power's MLX and SLX series modules operate over a wide input voltage range from 7 VDC to 14 VDC, providing PMBus programmable output voltages from 0.45 VDC to 2.0 VDC. The DLynx III power module features an advanced PID-based adjustable digital control loop that helps ensure loop stability, provides fast transient response, and reduces output capacitance requirements. Additional SLX ...

2023-04 Power Renesas Electronics America

[Apr 3 2023] Renesas's RAA271082 multitrack power supply IC features one primary high voltage synchronous step-down regulator, two secondary low voltage synchronous step-down regulators, and one LDO regulator. It provides four overvoltage (OV) and undervoltage (UV) monitors, I2C communications, a universal I/O pin and a dedicated reset output/failure indicator. A 4 mm x 4 mm 24 pin step cut QFN (SCQFN) packag ...

2023-04 Sensors Phoenix Contact

[Apr 3 2023] Phoenix Contact's LPTA 16 series provides a tool-free lever connection technology ideal for field device connections. The consistent PCB terminal block product line combines lever-driven high ease of use with reliable insertion spring connections. In the growing market for renewable energy, electric drives, and electric charging infrastructure, drives need to be connected quickly and securely. Fe ...
