Technology Articles

2023-03 Power Molex

[Mar 19 2023] Molex's 5G25 RF connector supports high frequency signals (25 GHz), while Molex's proprietary RF terminal contact shielding and isolation maintains the high level of signal integrity (SI) performance required for mission-critical 5G applications. The uniquely designed shield provides complete EMI shielding and high-frequency capabilities to achieve superior EMI reduction and SI performance, while ...

2023-03 Sensors TDK

[Mar 19 2023] EPCOS-TDK Electronics' B82559A*A033 Series shielded ERU33 High current chokes for through-hole installation are designed for high saturation currents from 32 A to 83 A at ±100°C and are available in six types covering a range of inductance values from 3.2µH to 10µH. Dc resistance as low as 0.85 mΩ or 1.2 mΩ, depending on the type. Due to the use of flat wire winding, the choke is very compact in ...

2023-03 Power KEMET

[Mar 19 2023] KEMET's PHA227 and PHH227 hybrid axial capacitors feature a polarized all-welded design with tinned copper wire leads with negative terminals connected to the housing. The winding is housed in a cylindrical aluminum can with a high purity aluminum lid and high quality rubber gaskets. The low ESR uses a highly conductive polymer (PEDOT/PSS) and an all-welded design. The polymer system creates an e ...

2023-03 Power 3M

[Mar 19 2023] 3M's track sand is a first class tool designed to optimize the performance of 3M abrasives. Equipped with powerful, precisely balanced air-driven motors and a durable lightweight aluminum housing, these ergonomically designed work horses can withstand industrial production and reduce user fatigue for hours of comfortable operation. Many styles are available for any application. From non-vacuum to ...

2023-03 Connectors 3M

[Mar 18 2023] Passive intermodulation can be a major obstacle to maintaining network performance, especially in towers with multiple frequency bands and near-antenna spacing. 3M's PIM Reduction Kit is an easy to install solution that reduces the PIM performed and time spent on the tower to achieve reliable service without disruptive outages. The PIM reduction suite is the solution to today's biggest signal int ...

2023-03 Power Recom Power

[Mar 18 2023] RECOM Power's RSOK-Z series is a cutting-edge DC/DC converter family with a wide 4:1 input voltage range of 9 VDC to 36 VDC. The converter features ON/OFF control for added convenience and precision. With high precision and tight line and load regulation, RSOK-Z ensures reliable performance even in challenging conditions. The device also includes continuous short circuit protection and undervolta ...

2023-03 Semiconductors STMicroelectronics

[Mar 18 2023] STM32WB1MMC wireless module is a cost-effective Bluetooth LE application integration solution. The STM32WB1MMC module imparts the entire reference design into the antenna, with the option of using an external antenna. The module is widely certified by FCC, CE and other EMC regulations. Based on the STM32WB15 WLCSP49 package, this module provides up to 27 GPIOs suitable for a range of peripherals ...

2023-03 Connectors Yageo

[Mar 18 2023] The PG2290, PGL6395 and PA5615 series of high current, low DCR inductors from Pulse Electronics, YAGEO, Inc., are combined for single-phase PoL and polyphase step-down converters, processors, memory modules for servers, data centers, network systems and graphics cards. fpga and ASICS power supply. All three series use the latest high-frequency materials that reduce core losses, reduce DCR, and pr ...

2023-03 Connectors ISSI, Integrated Silicon Solution Inc

[Mar 18 2023] The ISSI eMMC product family provides the ideal embedded storage solution for automotive, industrial, and medical applications that require high performance, endurance over a wide range of operating temperatures, and long-term support. These products are available for industrial and automotive grade 100-ball BGA and 153-ball BGA. EMMC integrates NAND flash memory and intelligent eMMC controllers ...

2023-03 Sensors Cornell Dubilier Electronics (CDE)

[Mar 17 2023] Cornell Dubilier's Model 944L DC Link capacitor is designed for fast switching power supply conversion applications. Their low inductance structure and low loss winding technology make them ideal for the design of the next generation of high power intensive inverters and converters. Sturdy plastic housing with integrated mounting flanges, threaded studs, or insert termination options for easy, sa ...

2023-03 Power Pulse Electronics

[Mar 17 2023] The PMS9505 series of Pulse Electronics from YAGEO has a unique construction. The primary winding is moulded into a plastic base to form a strong insulating barrier to achieve enhanced insulation, conforming to IEC60664/IEC60950-1, with operating voltages up to 300 VRMS. The PMS9505 features current sensing from a low DCR primary, allowing a current rating of 30 ARMS with turning ratios ranging f ...

2023-03 Power Renesas Electronics America

[Mar 17 2023] Renesas RA4E2 is the most optimized product in the RA4 range. It is based on the 100 MHz Arm®Cortex®-M33 core and offers a smaller package, lower pin count options, and a more optimized feature set than the existing RA4E1. It maintains the same performance range as several interfaces, such as I³C, CAN FD, and HDMI CEC, which were previously unavailable on RA4 devices. The RA4E2 can be the first e ...
