Technology Articles

2023-03 Power Texas Instruments

[Mar 17 2023] Texas Instruments' TPSM63610 is a highly integrated 36v, 8 a DC/DC solution that combines power MosFETs, shielded inductors and passivity in an enhanced HotRod QFN package. The module features VIN and VOUT pins located in the corners of the package to optimize the placement of input and output capacitors. Four larger heat pads below the module make the layout simple and easy to manufacture. With ...

2023-03 Power Texas Instruments

[Mar 17 2023] The OPA593 is a high-voltage (85 V), high-precision, wide-band (10 MHz), high-output current (250 mA), unity-gain stable power amp that uses laser fine-tuning technology to improve offset voltage (20µV typical) and offset voltage drift (0.4µV/°C typical), avoiding the need for calibration. The amplifier has a Mux-friendly input that enables differential input voltage ranges across the supply trac ...

2023-03 Semiconductors Texas Instruments

[Mar 16 2023] Texas Instruments' MCT8329A offers a single-chip, code-free sensorless ladder solution for three-phase brushless direct current (BLDC) motors that require high-speed operation or very fast start-up times. The device provides three half-gate drivers, each capable of driving both high - and low-side n-channel power MosFeTs. The device uses an internal charge pump to generate the correct grid drive ...

2023-03 Optoelectronics Taitien

[Mar 16 2023] Taitien's LoRa and LoRaWAN application-centric crystals provide tight tolerances for demanding operating environments, with initial accuracy of ±10 ppm and temperature stability of ±10 ppm in the range -40°C to +85°C. The XX, XY, XZ and X3 series have low acceleration or g sensitivity, and are standard with 26 MHz and 32 MHz. These output frequencies are used for long-range wireless data transmis ...

2023-03 Sensors Bourns

[Mar 16 2023] The Bourns AD and SD series resetable Miniature thermal fuse (TCO) circuit breaker devices are the first class of Bourns TCO devices that have passed the pressure test of the AEC-Q200 standard. The AD and SD series' advanced overheating protection technology makes them ideal solutions for a wide range of applications such as heaters, motors, cables and printed circuit board components. They also ...

2023-03 Semiconductors Texas Instruments

[Mar 16 2023] Texas Instruments' TPS92622-Q1 dual-channel LED driver includes a unique thermal management design to reduce temperature rise on the device. The TPS92622-Q1 is a linear driver powered directly from the car battery, with large voltage variations and a full current load of up to 150 mA per channel output. External shunt resistors are drivers that share output current and dissipated power. The devic ...

2023-03 Semiconductors Analog Devices

[Mar 16 2023] ADI's LT7200S is A four-channel, high-efficiency single-chip synchronous step-down regulator capable of pumping/pulling 5 A current into a load per channel. Due to its constant frequency, current mode architecture, and phase-locked controlled timing, it is ideal for high step-down ratio applications that operate at high frequencies and require fast transient responses. The LT200S 'multi-channel f ...

2023-03 Power Texas Instruments

[Mar 15 2023] The STMicroelectronics LM2903B contains two independent low-power voltage comparators specifically designed for use with a single power supply over a wide voltage range. It is fully specified to use 5 V and 36 V supply voltages; However, it can also be operated using a split power supply. In addition, the device has the unique property that the input common-mode voltage range includes the negativ ...

2023-03 Semiconductors STMicroelectronics

[Mar 15 2023] STMicroelectronics LIS2DUX12 is an intelligent digital 3-axis accelerometer. Its MEMS and ASics are specifically designed to combine the lowest possible current consumption with already-on-line features such as anti-aliasing filtering, finite state machine (FSM), and machine learning. The core (MLC) is combined with adaptive self-configuration (ASC). FSM and MLC with ASC provide LIS2DUX12 with ex ...

2023-03 Power Tripp Lite

[Mar 15 2023] Triplett's PS305 30 V/5 A DC power supply is a compact multipurpose power supply that weighs 8.8 lb (4 kg) and measures 4" x 6" x 8" (105 mm x 155 mm x 210 mm) (width x height x depth). It won't be bulky on the workbench or take up too much workbench space. It is portable and can be easily transported between test stations. For most applications, the PS305 provides the most commonly used 30 V/5 A ...

2023-03 Semiconductors STMicroelectronics

[Mar 15 2023] The ILPS28QSW from STMicroelectronics is an ultra-compact piezoresistive absolute pressure sensor that can be used as a digital output barometer. It supports dual-mode full scale up to 4,060 hPa, which can be selected by users. The device consists of a sensing element and an IC interface that enables communication between the sensing element and the application through an I²C or MIPI I³C® interfa ...

2023-03 Semiconductors STMicroelectronics

[Mar 15 2023] STMicroelectronics ST25-TAG-BAG-EC is a ready-to-use tag kit, Contains tags based on NFC Forum Type 5 tags IC (ST25TV512C and ST25TV02KC) and tags based on NFC Forum Type 2 tags IC (ST25TN512 and ST25TN01K). The ST25-TAG-BAG-EC is used to evaluate the ST25TV and ST25TN series NFC tags belonging to the ST25T product family. It provides advanced features for long range (ISO/IEC 15693) tags and shor ...
