Technology Articles

2023-03 Semiconductors Infineon Technologies

[Mar 8 2023] Infineon's MA2304DNS/MA2304PNS is a 2 x 37 W audio amplifier family that uses MERUS multilevel switching amplifier technology to achieve excellent efficiency at both low and high output power. Multilevel switches relax EMC requirements and enable inductorless applications at a lower cost. A high order internal feedback loop ensures low THD and high PSRR for excellent audio performance. The integr ...

2023-03 Power Schaffner EMC

[Mar 8 2023] Schaffner's FN3025 and FN3026 are designed for small and medium-sized industrial equipment with limited space. They provide very low leakage current. The DIN rail version (FN3026) is suitable for the popular TS 35 DIN rails on panel buildings and electrical cabinets. HP type has slightly better performance than HL type and higher ground leakage rate. They are rated at 520 volts. They have 10a, 20 ...

2023-03 Sensors Amphenol Piher Sensing Systems

[Mar 8 2023] Amphenol Piher Sensing Systems' PSCM is a non-contact multi-turn rotating position sensor based on Hall effect technology, which is a cost-effective alternative to absolute encoders. It is also well suited for replacing drawstring encoders by converting linear motion into angular position. In the case of power failure, the sensor will retain the last measured position. This compact yet rugged sen ...

2023-03 Sensors Amphenol Piher Sensing Systems

[Mar 8 2023] Amphenol Piher Sensing Systems' PS2P-ARC position sensors are not affected by radial and axial clearance on the pivot joint, thus avoiding poor operating performance and labor intensive maintenance schedules due to unaligned. Magnets are connected to pivot joints for rotating parts, and electronic modules are connected to the case (and vice versa). Sensors are easy to install without any gears or ...

2023-03 Power Molex

[Mar 7 2023] Molex's ACB6+ Series SlimStack board-to-board Connector offers upgraded performance with up to 5.0A power stud fully armored housing protection. With 0.35 mm pitch and 0.60 mm height, the connector provides plug-in guidance and electrical contact guarantees for superior reliability in challenging applications. The contact area is separated from the welding area (terminals and nails are separated ...

2023-03 Power Stewart Connector

[Mar 7 2023] Stewart Connector delivers reliability and functionality with its SealJack modular cable application series and RJ45 modular jack. The portfolio responds to the connectivity requirements for devices as Ethernet applications move from typical office conditions to harsh environments in the Internet of Things (IoT) era. Cable application series The SealJack Cable Application Series is IP67 Class pre ...

2023-03 Sensors TDK

[Mar 7 2023] TDK Corporation's EPCOS B43652* series bite-type aluminum electrolytic capacitors feature a very compact size and very high ripple current carrying capacity. Designed for a maximum rated voltage of 450 VDC, the RohS-compatible capacitors come in seven models covering a capacitance range from 270 µF to 820 µF. A typical application of these capacitors with high CV products is the DC link circuit o ...

2023-03 Semiconductors Infineon Technologies

[Mar 7 2023] Infineon's Radar Shield2Go can be used independently as a plug-in radar sensor (for example, using an Arduino contour board or other microcontroller) to detect motion and direction of motion by using only two GPIOs (TD and PD) in autonomous mode (default). The board comes with two potentiometers and switches that allow easy mechanical adjustment of the radar's four QS signals. These switches can ...

2023-03 Power KEMET

[Mar 6 2023] YAGEO KEMET's C28, C87 and C27 polypropylene metallized cylindrical film capacitors are designed for motor starting applications. They use FASTON, plastic decks or cable terminals, and overpressure safety devices. Each series is designed for the S3, S2 or S0 security level. Ac motor running capacitors are used to eliminate the induction effect of the AC motor and store charge while the motor is r ...

2023-03 Sensors TDK

[Mar 6 2023] TDK's ACT1210E series (3.2mm x 2.5mm x 2.5mm) is the industry's first common-mode filter designed specifically for automotive Ethernet 10BASE-T1S. The product uses TDK's proprietary wire winding structure and optimal materials to achieve excellent high-scattering parameters (S-parameters) and maximum line-to-line capacitance of 10pf, with operating temperatures ranging from -40℃ to +125℃. Laser w ...

2023-03 Power Traco Power

[Mar 6 2023] TRACO Power's TIB 240-124 BcmU modules convert any existing AC/DC 24 VDC power supply into a full-fledged uninterruptible power supply (UPS) system that supports up to 240 W of power, providing optimal charging and protection for connected lead-acid batteries. The integrated microprocessor ensures that the connected lead-acid battery is charged optimally and performs periodic impedance measuremen ...

2023-03 Semiconductors Texas Instruments

[Mar 6 2023] The Texas Instruments TPS631010 is a constant-frequency peak-current mode controlled step-up converter in a microwafer chip-level package. The converter features A 3 A peak current limit (typical), 1.6V to 5.5V input voltage range, and provides a power solution for system preregulators and regulators. Depending on the input voltage, when the input voltage is approximately equal to the output volt ...
