Technology Articles

2023-02 Power Murata Electronics

[Feb 27 2023] Murata MYR Series DC/DC converters are now included in 150 mA models with extremely small static current (IQ= 0.2μA). The product family integrates a coil and a control IC. Its ultra-small external dimensions are 2.5mm x 2.0mm x 1.0mm. The MYR series is much smaller than vertical solutions. In most cases, these modules take up less than half the space of the same solution implemented with discret ...

2023-02 Sensors TDK-EPCOS

[Feb 27 2023] TDK EPCOS ModCap is a modular capacitor concept suitable for DC link applications. The B25645A intermediate frequency power capacitor is suitable for rated voltages from 1,100 V to 2,300 V, covering the capacitance range from 365 µF to 3,900 µF. It is rated between 105 A and 180 A, with model limitations, and is designed for 5 kA periodic pulse current. The maximum allowable hot spot temperature ...

2023-02 Power ECS

[Feb 27 2023] ECS 'ECS-3215MV-327KE HCMOS oscillator comes in a 2.0mm x 1.2mm x 0.85mm ceramic package that provides MultiVolt functionality. These electronic components provide a frequency of 32.768 kHz, frequency stability of ±10 ppm, and low current consumption of 0.5 μA in the standard industrial operating temperature range from -40°C to +85°C. The ECS-2012MV-327KE belongs to the ECS MultiVolt oscillator f ...

2023-02 Power CUI

[Feb 27 2023] CIT Relay & Switch's DH30 Series fail-proof switches feature instantaneous or locking options, are 30 mm in size and feature SPST NO, SPST NC, DPST NO or DPST NC. They are made of stainless steel or anodized alumina body with IP67 seal rating. Embedded actuators with LED ring, dot light or no light options. LED voltages are 6 VDC, 12 VDC, 24 VDC, 110 VDC, or 220 VDC. LED color options include, bu ...

2023-02 Semiconductors Analog Devices

[Feb 26 2023] ADI's LTM4652 is A step-down DC-DC μModule voltage regulator with A pull/pump dual-channel ±25 A or single-channel ±50 A output switching mode with a total DC output error of ±1.5%. The LTM4652 operates in an input voltage range of 4.5V to 18V and supports dual outputs ranging from 0.6V to 7.5V, with each output set by an external resistor. The device is designed with high energy efficiency, prov ...

2023-02 Optoelectronics Bridgelux

[Feb 26 2023] For traditional LED technology, higher CRI results in lower light efficiency. Bridgelux's F90 LED product achieves CRI80 LED light efficiency with a CRI of 90 by replacing wide-band red phosphor phosphors with narrow band red potassium fluosilicate (PFS or KSF) phosphors. Lighting users can replace existing leds in lighting products with F90 leds to achieve CRI90 conversion. F90 series leds have ...

2023-02 Semiconductors NXP

[Feb 26 2023] ● Up to six IEEE 100BASE-T1 PHyS ● Single IEEE 100BASE-TX PHY ● Up to two MII/RMII/RGMII interfaces ● Up to four SGMII interfaces ● A host controller based on Arm® Cortex®-M7 NXP's SJA1110 family of Automotive Ethernet switches provides a rich set of security, safety and TSN features. The device is available in four models, each capable of supporting flexible modular ECUs designs for gateway, ADA ...

2023-02 Semiconductors Texas Instruments

[Feb 26 2023] Texas Instruments TLV61070A is a synchronous boost converter with an ultra-low input voltage of 0.5V that provides a power solution for portable devices and smart devices powered by a variety of batteries and supercapacitors. The typical valley switching current is limited to 2.5 A over the entire temperature range. The device has a wide input voltage range of 0.5 V to 5.5 V, supporting applicati ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] Texas Instruments ISOUSB111 is a current isolated USB 2.0 compatible repeater that supports both low (1.5 Mbps) and full (12 Mbps) signal rates. The device supports automatic connection and speed detection, pull-up/pull-down reflection, and link-layer power management and can be used for plug-in USB hubs, hosts, peripherals, and cable isolation. The device also supports automatic role reversal, w ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] The Texas Instruments LM5169 is a synchronous step-down converter designed to adjust over a wide input voltage range, minimizing the need for external surge suppression components. A controlled on-off time of 50 ns (minimum) helps achieve a large step-down conversion ratio that supports direct step-down from 48 V nominal input to the low rail, thereby reducing system complexity and solution cost. ...

2023-02 Power XP Power

[Feb 25 2023] XP Power's JMR03 series ultra-compact DC/DC converters are medically certified and designed for BF and CF grade applications. From DIP24 to DIP16 modules, the base surface of JMR03 is reduced by 45%, thus providing more PCB space for the user's components. The wide input range of 4:1 provides flexibility in power selection. Reduced no-load input standby current provides longer run times in portab ...

2023-02 Semiconductors Texas Instruments

[Feb 25 2023] Texas Instruments TPS61376 is a high voltage asynchronous boost converter with input average current limiting and real load disconnection. The average input current limit threshold can be set in 0.1A to 3.0A Settings via the ILIM pin. The isolation FETs between VP and SW pins will cut the path between input and output when the device is disabled. The converter has a wide input voltage range of 2. ...
